8268
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 14-16AWG #10 BLU
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.378062
≥1 USD $0.378062
≥10 USD $0.356658
≥100 USD $0.336464
≥500 USD $0.317428
≥1000 USD $0.299459
Inventory: 6972
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Length - Ring Center to Termination 0.250 6.35mm
Width - Outer Edges 0.320 8.13mm
Length - Overall 0.700 17.78mm
Length - Termination 0.450 11.43mm
Length 17.78mm
Technical
Stud/Tab Size 10 Stud
Terminal Type Spring, Snap
Insulation Insulated
Insulation Diameter 0.170 (4.32mm)
Terminal and Terminal Block Type FORK TERMINAL
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge 14-16 AWG
Contact Finish Tin
Orientation Straight
HTS Code 8536.90.40.00
Color Blue
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Bulk
Physical
Material - Insulation Vinyl
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper, ETP
Supply Chain
Factory Lead Time 6 Weeks
