BS-23-6-NB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 10-12AWG #6 YEL
PDF
/
Inventory: 5966
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Ring Center to Termination 0.290 7.37mm
Width - Outer Edges 0.320 8.13mm
Length - Overall 1.030 26.16mm
Length - Termination 0.550 13.97mm
Length 26.162mm
Technical
Stud/Tab Size 6 Stud
Terminal Type Flanged
Insulation Insulated
Insulation Diameter 0.250 (6.35mm)
Wire Gauge (Min) 10 AWG
Wire Gauge (Max) 12 AWG
Wire Gauge 10-12 AWG
Contact Finish Tin
Color Yellow
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Bulk
Physical
Material - Insulation Polyamide (PA), Nylon
Weight 1.995806g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper, ETP
Supply Chain
Factory Lead Time 3 Weeks
