BFV14-10Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
3M BFV14-10QTERMINAL, BLOCK FORK, STUD 10, CRIMP, BLUE
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.6688
≥1 USD $0.6688
≥10 USD $0.58256
≥100 USD $0.532576
≥500 USD $0.501248
≥1000 USD $0.480304
≥3000 USD $0.438557
Inventory: 111
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Length - Ring Center to Termination 0.250 6.35mm
Width - Outer Edges 0.300 7.62mm
Length - Overall 0.850 21.59mm
Length - Termination 0.450 11.43mm
Width 139.7mm
Length 21.59mm
Height 114.3mm
Technical
Stud/Tab Size 10 Stud
Terminal Type Standard
Insulation Insulated
Insulation Diameter 0.170 (4.32mm)
Wire/Cable Gauge 14 AWG
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge 14-16 AWG
Approval Agency CSA, UL
Contact Finish Tin
Orientation Straight
Voltage - Rated 1kV
Color Blue
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Butted Seam
Series Highland?
Published 2000
Packaging Bulk
Physical
Terminal Material Copper
Material - Insulation Vinyl
Weight 317.514659g
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper, ETP
Supply Chain
Factory Lead Time 3 Weeks
