94767
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Connectors, Interconnects / Terminals - Spade Connectors
Description
CONN SPADE TERM 18-22AWG #10 RED
PDF
/
Inventory: 2908
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Length - Ring Center to Termination 0.290 7.37mm
Width - Outer Edges 0.340 8.64mm
Length - Overall 0.900 22.86mm
Length - Termination 0.450 11.43mm
Width 8.64mm
Length 22.86mm
Technical
Stud/Tab Size 10 Stud
Terminal Type Standard
Insulation Insulated
Insulation Diameter 0.145 (3.68mm)
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge 18-22 AWG
Contact Finish Tin
Orientation Straight
Color Red
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Butted Seam
Series Highland?
Published 2002
Packaging Bulk
Physical
Material - Insulation Vinyl
Weight 997.903214g
Package / Case 100
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper, ETP
Supply Chain
Factory Lead Time 3 Weeks
Alternative Model
