52263-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 8AWG #10 CRIMP
PDF
/
Buying Options
Total Price: USD $1.08
Unit Price: USD $1.0824
≥1 USD $1.0824
≥10 USD $1.012
≥100 USD $0.973984
≥500 USD $0.964656
≥1000 USD $0.870584
≥3000 USD $0.842336
Inventory: 1108
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Copper
Contact Plating Tin
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Technical
Packaging Tape & Reel (TR)
Published 2007
Series Plasti-Grip
Feature Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Color Red
Gender Female
HTS Code 8536.90.40.00
Depth 10.95mm
Voltage - Rated AC 600V
Wire Gauge 8 AWG
Wire/Cable Gauge 8 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.330 (8.38mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 10 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 5 mm
Number of Holes 1
Dimensions
Length 4.7498mm
Thickness 0.040 1.02mm
Length - Overall 1.576 40.03mm
Width - Outer Edges 0.431 10.95mm
Tongue Thickness 1.02mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
