RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING SLOTTED 16-22AWG #6
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.776779
≥1 USD $0.776779
≥10 USD $0.732808
≥100 USD $0.691324
≥500 USD $0.6522
≥1000 USD $0.615282
Inventory: 7855
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tongue Thickness 840μm
Width - Outer Edges 0.281 7.14mm
Length - Overall 0.710 18.03mm
Thickness 0.031 0.79mm
Length 18.034mm
Technical
Stud Size M3.5
Stud Diameter 3.5052 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 6 Stud
Wire Cross Section 1.65 mm2
Wire/Cable Diameter 3.18 mm
Terminal Type Slotted
Insulation Non-Insulated
Insulation Diameter 0.080 ~ 0.125 (2.03mm ~ 3.18mm)
Terminal and Terminal Block Type FORK TERMINAL
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 22 AWG
ELV Compliant
Wire Gauge 16-22 AWG
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Serrated Termination
Series Diamond Grip
Published 2009
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 18 Weeks
