323914 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 22-26AWG #4 CRIMP
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.396
≥1 USD $0.396
≥10 USD $0.37048
≥100 USD $0.368544
≥500 USD $0.359216
≥1000 USD $0.308176
≥3000 USD $0.278714
Inventory: 20799
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)

Physical

Contact Material Copper
Contact Plating Tin
Mount Stud
Mounting Type Free Hanging (In-Line)
Material Copper
Material - Insulation Polyamide (PA), Nylon
Body Material Copper

Technical

Packaging Bulk
Published 1997
Series PIDG
Feature Serrated Termination
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Yellow
Gender Female
Orientation Straight
Depth 5.16mm
Contact Finish Tin
Voltage - Rated AC 300V
Wire Gauge 22-26 AWG
Plating Tin
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 22 AWG
Body Plating Tin
Wire/Cable Gauge 22 AWG
Sealable No
Insulation Diameter 0.050 ~ 0.082 (1.27mm ~ 2.08mm)
Insulation Insulated
Thread Size M2.5
Terminal Type Circular
Wire/Cable Diameter 2.08 mm
Stud/Tab Size 4 Stud
Insulated Wire Support Yes
Heavy Duty No
Stud Diameter 3.0226 mm
Government Qualified Yes
Number of Holes 1
Stud Size M2.5

Dimensions

Length 16.4084mm
Thickness 0.018 0.46mm
Length - Overall 0.646 16.41mm
Width - Outer Edges 0.203 5.16mm
Tongue Thickness 500μm

Compliance

Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
