321045 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 14-16AWG #1/4
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.3608
≥1 USD $0.3608
≥10 USD $0.32736
≥100 USD $0.272448
≥500 USD $0.202963
≥1000 USD $0.181166
≥3000 USD $0.16859
Inventory: 14504
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Tongue Thickness 790μm
Material Thickness 790μm
Width - Outer Edges 0.469 11.91mm
Length - Overall 1.078 27.38mm
Thickness 0.031 0.79mm
Width 11.9mm
Length 27.38mm

Technical

Stud Size M6
Number of Holes 1
Government Qualified No
Stud Diameter 6.731 mm
Heavy Duty No
Insulated Wire Support Yes
Stud/Tab Size 1/4 Stud
Wire/Cable Diameter 4.318 mm
Terminal Type Circular
Thread Size M6
Insulation Insulated
Insulation Diameter 0.115 ~ 0.170 (2.92mm ~ 4.32mm)
Sealable No
Body Plating Tin
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
Plating Tin
ELV Compliant
Wire Gauge 14-16 AWG
Voltage - Rated AC 300V
Contact Finish Tin
Depth 11.91mm
Orientation Straight
Gender Female
Color Blue
Max Operating Temperature 105°C
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Serrated Termination
Series PIDG
Published 2007
Packaging Bulk

Physical

Body Material Copper
Material - Insulation Polyamide (PA), Nylon
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 4 Weeks
