165299 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description Ring Tongue Terminal 13.5-17AWG 21.5mm 11mm Tin Strip
PDF
/
Inventory: 1543
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 14 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 months ago)

Physical

Contact Material Copper
Mounting Type Free Hanging (In-Line)

Technical

Packaging Bulk
Published 1997
Series Solistrand
Feature Serrated Termination
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 11mm
Wire Gauge 14-16 AWG
ELV Compliant
Plating Tin
Wire Gauge (Max) 17 AWG
Wire Gauge (Min) 5 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Circular
Wire Cross Section 2 mm2
Stud/Tab Size 1/4 Stud
Insulated Wire Support No
Stud Diameter 6.5 mm
Number of Holes 1
Stud Size M6

Dimensions

Length 21.895mm
Thickness 0.031 0.79mm
Width - Outer Edges 0.433 11.00mm
Material Thickness 800μm
Tongue Thickness 800μm

Compliance

RoHS Status RoHS Compliant
Lead Free Not Applicable
