7-51864-1
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 16AWG #10 CRIMP
PDF
/
Inventory: 3476
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Insulation Material Nylon
Technical
Packaging Bulk
Pbfree Code yes
Termination Circular
ECCN Code EAR99
Color Blue
HTS Code 8536.90.40.00
Voltage - Rated AC 300V
ELV Compliant
Wire/Cable Gauge 16 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 3.3 mm
Insulation Insulated
Wire/Cable Diameter 3.81 mm
Insulated Wire Support Yes
Heavy Duty No
Terminal Gender FEMALE
Stud Diameter 5 mm
Number of Holes 1
Dimensions
Length 23mm
Thickness 787.4μm
Material Thickness 838.2μm
Tongue Thickness 790μm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
