0190670081
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 4AWG 46.99mm 12.06mm Electro-Tin NylaKrimp? Bag
PDF
/
Buying Options
Total Price: USD $1.92
Unit Price: USD $1.917726
≥1 USD $1.917726
≥10 USD $1.809177
≥100 USD $1.706774
≥500 USD $1.610159
≥1000 USD $1.519014
Inventory: 2129
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Copper
Mounting Type Free Hanging (In-Line)
Material - Insulation Polyamide (PA), Nylon
Technical
Packaging Bulk
Series NylaKrimp
Feature Brazed Seam
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Yellow
Contact Finish Electro-Tin
Wire Gauge 4 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.510 (12.95mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 10 Stud
Dimensions
Thickness 0.067 1.70mm
Length - Overall 1.850 46.99mm
Width - Outer Edges 0.475 12.07mm
Compliance
RoHS Status ROHS3 Compliant
