0190540083
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminal Ring Connector
PDF
/
Inventory: 7264
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Technical
Packaging Bulk
Series InsulKrimp
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Blue
Contact Finish Electro-Tin
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.175 (4.45mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 8 Stud
Dimensions
Length 21.209mm
Thickness 0.031 0.79mm
Length - Overall 0.835 21.20mm
Width - Outer Edges 0.250 6.35mm
Compliance
RoHS Status ROHS3 Compliant
