13-716-NB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 10-12AWG #7/16
PDF
/
Inventory: 3111
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 3.489996g
Material - Insulation Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2015
Feature Butted Seam
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Yellow
Wire Gauge 10-12 AWG
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Insulation Diameter 0.250 (6.35mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 7/16 Stud
Dimensions
Length 28.448mm
Thickness 0.040 1.02mm
Length - Overall 1.120 28.45mm
Width - Outer Edges 0.750 19.05mm
Compliance
RoHS Status ROHS3 Compliant
