326105 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description CONN TERM RECT 500 MCM #1/2
PDF
/
Buying Options
Total Price: USD $24.14
Unit Price: USD $24.1384
≥1 USD $24.1384
≥10 USD $19.92408
≥100 USD $18.519424
≥500 USD $17.497744
≥1000 USD $17.114592
≥3000 USD $16.986842
Inventory: 181
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Copper

Technical

Packaging Bulk
Published 1998
Series Ampower
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp, Barrel
Gender Female
Orientation Straight
Contact Finish Tin
Wire Gauge 500MCM (kcmil)
ELV Compliant
Plating Tin
Sealable No
Insulation Non-Insulated
Terminal Type Standard
Stud/Tab Size 1/2 Stud
Terminal Style Single Stud Hole
Insulated Wire Support No
Heavy Duty No
Stud Diameter 13.08 mm
Government Qualified No
Number of Holes 1
Stud Size M12

Dimensions

Length 83.57mm
Thickness 5.08mm
Length - Overall 3.290 83.57mm
Diameter - Inside 24.92 mm
Width - Outer Edges 1.800 45.72mm
Tab Thickness 0.200 5.08mm
Tongue Thickness 5.08mm
Diameter - Barrel ID 0.981 (24.92mm)
Diameter - Barrel OD 1.219 (30.96mm)
Diameter - Ring ID 0.515 (13.08mm)

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
