LCD750-58G-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (9.5/0)AWG 138.7mm 48mm Tin
PDF
/
Inventory: 935
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.660 (16.76mm)
Diameter - Barrel OD 1.300 (33.02mm)
Diameter - Barrel ID 1.030 (26.16mm)
Tab Thickness 0.260 6.60mm
Width - Outer Edges 1.890 48.01mm
Length - Overall 5.460 138.68mm
Length 138.684mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 5/8 Stud
Wire Cross Section 484 mm2
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge 750MCM (kcmil)
Contact Finish Electro-Tin
Depth 48mm
HTS Code 8536.90.40.00
Color Black
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2005
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
