LCD6-14A-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT TONG 6 AWG #1/4
PDF
/
Buying Options
Total Price: USD $14.5
Unit Price: USD $14.497042
≥1 USD $14.497042
≥200 USD $5.784637
≥500 USD $5.591641
≥1000 USD $5.495799
Inventory: 6569
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
Color Blue
Contact Finish Electro-Tin
Wire Gauge 6 AWG
Wire/Cable Gauge 6 AWG
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/4 Stud
Terminal Style Two Stud Holes
Dimensions
Length 56.896mm
Length - Overall 2.240 56.90mm
Width - Outer Edges 0.480 12.19mm
Tab Thickness 0.080 2.03mm
Diameter - Barrel ID 0.220 (5.59mm)
Diameter - Barrel OD 0.310 (7.87mm)
Diameter - Ring ID 0.270 (6.86mm)
Compliance
RoHS Status ROHS3 Compliant
