173860-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 9014
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width - Tab 1.8034mm
Tab Thickness 640μm
PCB Thickness 1.6mm
Width 49.8mm
Length 24.92mm
Technical
Circuit Application Signal
Max Voltage Rating (DC) 12V
ELV Compliant
Row Spacing - Mating 5.8928 mm
Shielding Unshielded
Orientation Right Angle
Pitch 3.5mm
Number of Rows 2
Color Blue
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 14
Connector Type Receptacle, Tab
Termination Solder
Packaging Bulk
Physical
Mount Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
