LCAX3/0-14-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (3/0)AWG 52.8mm 26.9mm Tin
PDF
/
Buying Options
Total Price: USD $10.08
Unit Price: USD $10.076
≥1 USD $10.076
≥10 USD $9.80056
≥100 USD $9.52864
≥500 USD $9.256368
≥1000 USD $8.984096
≥3000 USD $8.711894
Inventory: 49
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.270 (6.86mm)
Diameter - Barrel OD 0.710 (18.03mm)
Diameter - Barrel ID 0.570 (14.48mm)
Tab Thickness 0.140 3.56mm
Width - Outer Edges 1.060 26.92mm
Length - Overall 2.080 52.83mm
Length 52.832mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 1/4 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Body Plating Tin
Wire Gauge 3/0 AWG
Contact Finish Electro-Tin
Depth 26.9mm
HTS Code 8536.90.40.00
Color Orange
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
