LCAX3/0-12F-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (3/0)AWG 52.6mm 26.9mm Tin
PDF
/
Buying Options
Total Price: USD $12.45
Unit Price: USD $12.452
≥1 USD $12.452
≥10 USD $12.11936
≥100 USD $11.782144
≥500 USD $11.445632
≥1000 USD $11.109032
≥3000 USD $10.772397
Inventory: 50
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Technical
Packaging Bulk
Published 2004
Series Pan-Lug?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
Color Orange
HTS Code 8536.90.40.00
Depth 26.9mm
Contact Finish Electro-Tin
Wire Gauge 3/0 AWG
Body Plating Tin
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 1/2 Stud
Terminal Style Single Stud Hole
Dimensions
Length 52.6mm
Width - Outer Edges 1.060 26.92mm
Tab Thickness 0.140 3.56mm
Diameter - Barrel ID 0.570 (14.48mm)
Diameter - Barrel OD 0.710 (18.03mm)
Diameter - Ring ID 0.530 (13.46mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
