LCAN300-38-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (5.5/0)AWG 74.7mm 20.6mm Tin
PDF
/
Buying Options
Total Price: USD $38.17
Unit Price: USD $38.172568
≥1 USD $38.172568
≥200 USD $15.230953
≥500 USD $14.722861
≥1000 USD $14.470784
Inventory: 6497
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.410 (10.41mm)
Diameter - Barrel OD 0.810 (20.57mm)
Diameter - Barrel ID 0.650 (16.51mm)
Tab Thickness 0.200 5.08mm
Width - Outer Edges 0.810 20.57mm
Length - Overall 2.960 75.18mm
Length 75.184mm
Technical
Terminal Gender FEMALE
Terminal Style Single Stud Hole
Stud/Tab Size 3/8 Stud
Wire Cross Section 194 mm2
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Safety Approval CSA; UL
Terminal and Terminal Block Type RING TERMINAL
Body Plating Tin
Wire Gauge 300MCM (kcmil)
Contact Finish Electro-Tin
Depth 20.6mm
HTS Code 8536.90.40.00
Color White
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2011
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
