LCA300-58F-X
RoHS
RoHS compliant
RoHS compliantPackage 300
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (5.5/0)AWG 60.7mm 30.2mm Tin
PDF
/
Inventory: 2726
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter - Ring ID 0.660 (16.76mm)
Diameter - Barrel OD 0.810 (20.57mm)
Diameter - Barrel ID 0.650 (16.51mm)
Tab Thickness 0.160 4.06mm
Width - Outer Edges 1.190 30.23mm
Length 60.7mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 5/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Body Plating Tin
Wire Gauge 300MCM (kcmil)
Contact Finish Electro-Tin
Depth 30.2mm
HTS Code 8536.90.40.00
Color White
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Pan-Lug?
Published 2011
Packaging Bulk
Physical
Package / Case 300
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
