LCA1-38H-E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Pan-Lug? ROHS3Compliant 2006 Non-Insulated Terminal Rectangular Connector 1AWG 0.360 (9.14mm)
PDF
/
Inventory: 3866
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), 45° Angle
Technical
Packaging Bulk
Published 2006
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
Color Green
Contact Finish Electro-Tin
Wire Gauge 1 AWG
Wire/Cable Gauge 1 AWG
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 3/8 Stud
Terminal Style Single Stud Hole
Dimensions
Width - Outer Edges 0.700 17.78mm
Tab Thickness 0.110 2.79mm
Diameter - Barrel ID 0.360 (9.14mm)
Diameter - Barrel OD 0.470 (11.94mm)
Diameter - Ring ID 0.410 (10.41mm)
Compliance
RoHS Status ROHS3 Compliant
