IPD1-02-D image
Favorite
IPD1-02-D image
Favorite

IPD1-02-D

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description CONN RCPT HSG 4POS 2.54MM
PDF
/
Buying Options
Total Price: USD $0.98
Unit Price: USD $0.9768
≥1 USD $0.9768
≥10 USD $0.8272
≥100 USD $0.79376
≥500 USD $0.776864
≥1000 USD $0.743072
≥3000 USD $0.675488
Inventory: 893
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Length 6.48mm

Technical

Contact Termination Crimp
Max Voltage Rating (DC) 848V
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 30 AWG
Max Current Rating 7.4A
Max Voltage Rating (AC) 600V
Note Contacts Not Included
Row Spacing 0.100 (2.54mm)
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Depth 12.83mm
Orientation Straight
Total Number of Contacts 4
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Latch Lock
Additional Feature SHROUDED
Gender Female
Number of Rows 2
Color White
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 4
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Mini Mate? IPD1
Published 2008
Packaging Bulk

Physical

Housing Material Nylon
Shell Material ZYTEL 103FHS
Mounting Type Free Hanging (In-Line)
Mount Free Hanging

Supply Chain

Factory Lead Time 3 Weeks
