CX35-36-CY
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT LUG 6-14AWG #3/16
PDF
/
Inventory: 5941
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Diameter - Ring ID 0.200 (5.08mm)
Tab Thickness 0.070 1.78mm
Width - Outer Edges 0.380 9.65mm
Length 9.7mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size 3/16 Stud
Terminal Type Lug, Grounding
Insulation Non-Insulated
Wire/Cable Gauge 6 AWG
Wire Gauge (Min) 6 AWG
Wire Gauge (Max) 14 AWG
Wire Gauge 6-14 AWG
Depth 9.65mm
HTS Code 8536.90.40.00
Gender Male
Type Mechanical
Connector Type Lug
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature With Screw
Series CX
Published 2008
Packaging Bulk
Physical
Weight 957.079901g
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
