CS25-18-CY

Panduit Corp
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Terminal Rectangular Connector
PDF
/
Inventory: 9452
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Tab Thickness 0.070 1.78mm
Width - Outer Edges 0.313 7.95mm
Length - Overall 1.161 29.50mm
Length 29.4894mm

Technical

Terminal Gender FEMALE
Terminal Style Single Stud Hole
Stud/Tab Size 1/8 Stud
Terminal Type Lug, Grounding
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire Gauge (Min) 10 AWG
Wire Gauge (Max) 14 AWG
Wire Gauge 10-14 AWG
Contact Finish Tin
Depth 8.12mm
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature With Screw
Series CS
Published 2011
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
