0357181710

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Quick Connects, Quick Disconnect Connectors
Description Quick Disconnect Terminal 16AWG F Tin Reel
PDF
/
Inventory: 5087
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width - Tab 0.187 4.75mm
Tab Thickness 0.020 0.51mm
Length - Overall 0.622 15.80mm
Length 15.7988mm

Technical

Length - Tab 0.224 5.70mm
Terminal Type Standard
Insulation Non-Insulated
Insulation Diameter 0.142 (3.61mm)
Wire/Cable Gauge 16 AWG
Body Plating Tin
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 20 AWG
Wire Gauge 16-20 AWG
Contact Finish Tin
Orientation Straight
Gender Female
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 35718
Packaging Reel

Physical

Body Material Brass
Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Brass

Supply Chain

Factory Lead Time 11 Weeks
