RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description Circuit Board Hardware - PCB MICRO PIN SWAGE MOUNT .051"
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.299642
≥1 USD $0.299642
≥10 USD $0.282682
≥100 USD $0.266679
≥500 USD $0.251589
≥1000 USD $0.237344
Inventory: 7713
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Length - Above Flange 0.312 7.92mm
Length - Below Flange 0.051 1.30mm
Board Thickness 0.032 0.81mm
Length - Overall 0.393 9.98mm
Contact Finish Thickness 10.0μin 0.25μm
Length 9.9822mm

Technical

Pin Size - Above Flange 0.032 0.81mm Dia
Terminal Style Single End
Flange Diameter 0.078 (1.98mm)
Hole Diameter 1.3208 mm
Terminal Type PC Pin
Insulation Non-Insulated
Connector Type INTERCONNECTION DEVICE
ECCN Code EAR99
Termination Swage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2007
Packaging Bulk

Physical

Mounting Hole Diameter 0.052 (1.32mm)
Material Gold
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass

Supply Chain

Factory Lead Time 6 Weeks
