714-87-147-41-001101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
714 ROHS3Compliant 2012 Gold Pin Receptacle Connector -55C~125C 0.039-0.102 1.00mm-2.60mm
PDF
/
Inventory: 3788
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Board Thickness 0.039 ~ 0.102 1.00mm ~ 2.60mm
Length - Overall 0.165 4.19mm
Contact Finish Thickness Flash
Length 4.191mm
Technical
Insertion Force 2.00N
Socket Depth 0.146 3.71mm
Accepts Pin Diameter 0.016 ~ 0.022 (0.41mm ~ 0.56mm)
Tail Type No Tail
Flange Diameter 0.072 (1.83mm)
Hole Diameter 1.8034 mm
Contact Finish Gold
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 714
Published 2012
Packaging Strip
Operating Temperature -55°C~125°C
Physical
Mounting Hole Diameter 0.055 ~ 0.071 (1.40mm ~ 1.80mm)
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 10 Weeks
