1419-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
Terminal Socket Connector
PDF
/
Buying Options
Total Price: USD $1.2
Unit Price: USD $1.201589
≥1 USD $1.201589
≥10 USD $1.13358
≥100 USD $1.069406
≥500 USD $1.008878
≥1000 USD $0.95177
Inventory: 7586
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Inside 1.17 mm
Length - Overall 0.355 9.02mm
Contact Finish Thickness 10.0μin 0.25μm
Length 9.017mm
Technical
Socket Depth 0.200 5.08mm
Accepts Pin Diameter 0.032 ~ 0.046 (0.81mm ~ 1.17mm)
Tail Type No Tail
Flange Diameter 0.125 (3.18mm)
Hole Diameter 1.7018 mm
Contact Finish Gold
Connector Type INTERCONNECTION DEVICE
Termination Swage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2000
Packaging Bulk
Physical
Mounting Hole Diameter 0.067 (1.70mm)
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 6 Weeks
