1869950000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Omnimate LSF-SMT RoHS Compliant Straight Vertical with Board Wire Board Terminal Block UL94V-0 24AWG -50C~240C 12A
PDF
/
Inventory: 5817
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Contact Material - Plating Copper Alloy - Tin Plated
Technical
Operating Temperature -50°C~240°C
Packaging Tube
Series Omnimate LSF-SMT
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
ECCN Code EAR99
Color Black
Number of Rows 1
Voltage - Rated 300V
Additional Feature GLASS FILLED LCP, 94V-0
Pitch 0.150 3.81mm
Orientation Straight
Current Rating 10A
Approval Agency CSA, cURus
Number of Contacts 8
Wire Gauge 16-24 AWG
Number of Levels 1
Current 12A
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 16 AWG
Number of Decks 1
Terminal and Terminal Block Type MODULAR TERMINAL BLOCK
Number of Ways 8
Safety Approval UL; VDE; CSA
Mating Orientation Vertical with Board
Wire Termination Screwless - Push Button Clamp
Hole Diameter 1.1 mm
Stripping Length 8mm
Fastening Method PUSH-ON
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
