0395437009

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description Conn Eurostyle Block 9 POS 5mm Solder ST Thru-Hole 15A/Contact Eurostyle?
PDF
/
Inventory: 5267
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Contact Material Brass, Steel
Contact Plating Brass, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material - Plating Brass - Tin Plated
Clamp Material - Plating Brass
Screw Material - Plating Steel

Technical

Operating Temperature -40°C~105°C
Packaging Bulk
Series Eurostyle ESE 39543
Feature Positions Stamped
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Color Black
Pitch 0.197 5.00mm
Orientation Straight
Depth 10mm
Number of Contacts 9
Wire Gauge 14-22 AWG
Max Supply Voltage 300V
Plating Brass, Steel
Number of Levels 1
Current 15A
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 14 AWG
Wire/Cable Gauge 14 AWG
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Torque - Screw 0.51 Nm (4.5 Lb-In)
Positions Per Level 9
Mating Orientation Horizontal with Board
Wire Termination Screw - Rising Cage Clamp

Dimensions

Length 45mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
