44432-0802
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Wire to Board HDR 8 POS 3mm Solder ST Thru-Hole Micro-Fit 3.0 BMI? Frame
PDF
/
Buying Options
Total Price: USD $2.87
Unit Price: USD $2.873434
≥1 USD $2.873434
≥10 USD $2.710794
≥100 USD $2.557348
≥500 USD $2.412593
≥1000 USD $2.27603
Inventory: 7362
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 15μin
Length 19mm
Technical
Glow Wire Compliant Non-compliant
Withdrawl Force-Min 3.614 N
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 250.25kV
Durability 30 Cycles
Dielectric Withstanding Voltage 1500VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 250V
Body/Shell Style RECEPTACLE
Insulation Resistance 1GOhm
Contact Resistance 100mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
UL Flammability Code 94V-0
Body Breadth 0.469 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Lead Pitch 3mm
Number Of PCB Rows 2
Row Spacing - Mating 2.9972 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 5A
Depth 11.9mm
Orientation Vertical
Total Number of Contacts 8
Pitch 3mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Additional Feature POLARIZED
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 8
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Pbfree Code yes
Physical
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Gold
Contact Material Brass
