3041626
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Specialized
Description
DIN Rail Terminal Blocks SC 2.5-RZ/13
PDF
/
Inventory: 1292
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Terminal Width 5.2mm
Width 67.6mm
Length 2.661 67.59mm
Height 21.7932mm
Technical
Stripping Length 10mm
Current - IEC 24A
Wire Gauge or Range - mm2 0.08-4mm2
Voltage - IEC 500V
Wire Gauge or Range - AWG 12-26 AWG
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 26 AWG
Current 20A
Number of Levels 1
Voltage 300V
Housing Color Gray
Termination Style Spring Cage
Current Rating 24A
HTS Code 8536.69.40.40
Voltage - Rated 500V
Color Grey
Number of Positions 13
Type Receptacle, Male Pins
ECCN Code EAR99
Termination IDC
Part Status Active
Pbfree Code yes
Feature Coupling, Engagement Pin
Series CLIPLINE COMBI SC
Published 2011
Physical
Material - Insulation Polyamide (PA), Nylon
Weight 41.600005g
Material Polyamide
Mounting Type Panel Mount
Mount Panel
Supply Chain
Factory Lead Time 6 Weeks
