1599270000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description
TERM BLK HDR 16POS SCREW MNT ORG
PDF
/
Inventory: 921
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.974 100.94mm
Length 102mm
Height 17.5mm
Technical
Rear Panel Wire Connection Quick Connect - 0.110 (2.80mm), Solder Eyelet
Front Panel Wire Connection Header, Male Pins
Fastening Method PLUG IN
Wire Cross Section 2.5 mm2
Safety Approval UL; CSA
Number of Ways 16
Terminal and Terminal Block Type MODULAR TERMINAL BLOCK
Number of Decks 1
Number of Poles 16
Current 15A
Number of Levels 1
Voltage 300V
Approval Agency CSA, UR
Current Rating 15A
Pitch 0.200 5.08mm
HTS Code 8536.69.40.40
Additional Feature STANDARD: UL 94V-0
Voltage - Rated 300V
Number of Rows 1
Color Orange
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Feature Lock Opening
Series Omnimate SLDF
Published 2008
Packaging Box
Physical
Panel Mount Type Screw Mount - Front Flange
Housing Material Plastic
Mounting Type BOARD
Contact Plating Tin
Contact Material CuSn
Supply Chain
Factory Lead Time 12 Weeks
