RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Panel Mount
Description Pluggable Terminal Blocks 9 Pos 10.16mm pitch Feed Thru Invert Hdr
PDF
/
Inventory: 1207
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Number of Ways 9
Safety Approval UL
Front Panel Wire Connection Header, Female Sockets
Rear Panel Wire Connection PCB Pins - Straight
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Decks 1
Current 5A
Number of Levels 1
Voltage 600V
Current Rating 76A
Pitch 0.400 10.16mm
Voltage - Rated 1kV
Number of Rows 1
Color Green
Number of Positions 9
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Threaded Mating Lock, Shield Connection Front Side
Series COMBICON DFK-IPCV
Published 2011

Dimensions

Width 5.217 132.52mm
Panel Thickness 0.039 ~ 0.118 1.0 ~ 3.0mm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-0

Physical

Panel Mount Type 2 Piece, Snap Lock - Front Flange
Weight 44.090001g
Mounting Type BOARD AND PANEL
Contact Material Silver

Supply Chain

Factory Lead Time 7 Weeks
