691366110012
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Header
PDF
/
Buying Options
Total Price: USD $9.36
Unit Price: USD $9.3632
≥1 USD $9.3632
≥10 USD $8.5008
≥100 USD $7.98688
≥500 USD $7.30048
≥1000 USD $5.927698
Inventory: 67
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Screw Size M2
Wire Strip Length 6-7mm
Wire Gauge or Range - mm2 0.08-1.31mm2
Plug Wire Entry 90°
Positions Per Level 12
Torque - Screw 0.2 Nm (1.7 Lb-In)
Current - UL 8A
Wire Gauge or Range - AWG 16-28 AWG
Voltage - UL 300V
Number of Levels 1
Termination Style Screw - Leaf Spring, Wire Guard
Insulation Height 0.760 19.30mm
Pitch 0.138 3.50mm
Color Green
Number of Positions 12
Type Plug, Female Sockets
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series WR-TBL Series 3661
Packaging Bulk
Operating Temperature -40°C~105°C
Physical
Housing Material Polyamide (PA66), Nylon 6/6
Mounting Type Free Hanging (In-Line)
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
