5773633
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
SAFETY APPROVAL: VDE Terminal Block Plug
PDF
/
Buying Options
Total Price: USD $48.25
Unit Price: USD $48.247762
≥1 USD $48.247762
≥200 USD $19.251053
≥500 USD $18.609045
≥1000 USD $18.29001
Inventory: 9025
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Wire Cross Section 2.5 mm2
Screw Size M3
Wire Strip Length 7mm
Wire Gauge or Range - mm2 0.2-2.5mm2
Plug Wire Entry 180°
Safety Approval CB; CSA; CUL; EAC; GL; RS; UL
Number of Ways 20
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Voltage - IEC 250V
Wire Gauge or Range - AWG 12-30 AWG
Contact Mating Finish Tin
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 30 AWG
Number of Levels 1
Termination Style Screw - Rising Cage Clamp
Current Rating 12A
Reach Compliance Code not_compliant
Insulation Height 0.591 15.00mm
Pitch 0.200 5.08mm
Additional Feature SAFETY APPROVAL: VDE
Voltage - Rated 250V
Color Green
Number of Positions 20
Type Plug, Female Sockets
Connector Type Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Mating Flange, Positions Stamped
Series COMBICON MSTB
Published 2014
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Supply Chain
Factory Lead Time 4 Weeks
