5433901
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks BCH-508V- 3
PDF
/
Buying Options
Total Price: USD $0.93
Unit Price: USD $0.929533
≥1 USD $0.929533
≥200 USD $0.371551
≥500 USD $0.358422
≥1000 USD $0.35317
Inventory: 5526
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2014
Series BCH
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Header, Male Pins, Shrouded (2 Side)
Number of Positions 3
Color Gray
Pitch 0.200 5.08mm
Depth 8.6mm
Insulation Height 0.472 12.00mm
Termination Style Solder
Housing Color Grey
Voltage 300V
Contact Tail Length 0.154 3.90mm
Max Current Rating 12A
Number of Levels 1
Current 15A
Contact Mating Finish Tin
Voltage - IEC 400V
Header Orientation Vertical
Current - IEC 12A
Dimensions
Length 15.16mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
