3521-08-0100-99
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN RCPT 8POS 0.1 TIN PCB
PDF
/
Buying Options
Total Price: USD $0.85
Unit Price: USD $0.8536
≥1 USD $0.8536
≥10 USD $0.67467
≥100 USD $0.645269
≥500 USD $0.527947
≥1000 USD $0.469286
≥3000 USD $0.410626
Inventory: 2345
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Material Bronze
Mounting Type Through Hole
Insulation Material Polyamide (PA9T), Nylon 9T
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Kinked Pin, Solder
Connector Type Receptacle
Number of Positions 8
Number of Rows 2
Voltage - Rated 500V
Fastening Type Push-Pull
Contact Finish - Mating Tin
Contact Type Forked
Current Rating (Amps) 1A
Insulation Height 0.157 4.00mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Red
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
