Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description COMBICON MC RoHS Compliant 2011 Mating Flange Terminal Block Plug, Female Sockets 16AWG 180° 8A 300V
PDF
/
Buying Options
Total Price: USD $5.87
Unit Price: USD $5.873358
≥1 USD $5.873358
≥10 USD $5.540908
≥100 USD $5.227267
≥500 USD $4.93138
≥1000 USD $4.652247
Inventory: 8200
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Screw Size M2
Wire Strip Length 7mm
Wire Gauge or Range - mm2 0.14-1.5mm2
Plug Wire Entry 180°
Torque - Screw 0.22-0.25 Nm (1.9-2.2 Lb-In)
Voltage - IEC 160V
Wire Gauge or Range - AWG 14-30 AWG
Contact Mating Finish Gold
Wire Gauge (Min) 28 AWG
Wire Gauge (Max) 16 AWG
Current 8A
Number of Levels 1
Voltage 300V
Termination Style Screw - Rising Cage Clamp
Current Rating 8A
Reach Compliance Code not_compliant
Insulation Height 0.437 11.10mm
Pitch 0.150 3.81mm
Voltage - Rated 160V
Color Green
Number of Positions 5
Type Plug, Female Sockets
Connector Type Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Mating Flange
Series COMBICON MC
Published 2011
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Mount Free Hanging

Supply Chain

Factory Lead Time 5 Weeks
