OSTEV236151
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Plug
PDF
/
Buying Options
Total Price: USD $71.28
Unit Price: USD $71.278654
≥1 USD $71.278654
≥200 USD $28.441353
≥500 USD $27.490813
≥1000 USD $27.020795
Inventory: 1288
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Phosphor Bronze
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Number of Pins 23
Housing Material Thermoplastic
Technical
Operating Temperature -30°C~105°C
Packaging Bulk
Series OSTEV
Feature Mating Flange
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Plug, Female Sockets
Number of Positions 23
Max Operating Temperature 105°C
Min Operating Temperature -30°C
Color Green
Pitch 0.400 10.16mm
Termination Style Screw
Voltage 600V
Number of Levels 1
Current 55A
Wire Gauge (Max) 20 AWG
Wire Gauge (Min) 6 AWG
Contact Mating Finish Tin
Voltage - UL 600V
Wire Gauge or Range - AWG 6-20 AWG
Current - UL 55A
Voltage - IEC 1kV
Torque - Screw 1.2 Nm (10.6 Lb-In)
Positions Per Level 23
Wire Gauge or Range - mm2 0.5-16mm2
Wire Strip Length 13-14mm
Current - IEC 76A
Number of Positions Per Level 23
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
