0395290003
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Socket
PDF
/
Inventory: 6562
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series Eurostyle ESE 39529
Feature Positions Stamped, Retention Latches (Wire Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Plug, Female Sockets
Number of Positions 4
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Number of Rows 1
Pitch 0.197 5.00mm
Orientation Straight
Insulation Height 1.020 25.91mm
Termination Style Screw - Rising Cage Clamp
Number of Contacts 3
Voltage 300V
Number of Levels 1
Current 15A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 12 AWG
Voltage - UL 300V
Wire Gauge or Range - AWG 12-26 AWG
Current - UL 15A
Torque - Screw 0.56 Nm (5.0 Lb-In)
Positions Per Level 4
Plug Wire Entry 90°
Wire Strip Length 5mm
Number of Positions Per Level 4
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
