ELXT046G0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Socket
PDF
/
Inventory: 5068
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA46), Nylon 4/6
Technical
Operating Temperature 125°C
Packaging Tray
Published 2006
Series ELXT
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
ECCN Code EAR99
Type Plug, Female Sockets
Number of Positions 4
Color Green
Number of Rows 1
Gender Female
Pitch 0.138 3.50mm
Orientation Straight
Depth 18.74mm
Insulation Height 0.738 18.75mm
Termination Style Screw - Rising Cage Clamp
Number of Contacts 4
Housing Color Black
Voltage 300V
Max Current Rating 12A
Number of Levels 1
Current 12A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 16 AWG
Contact Mating Finish Tin
Number of Decks 1
Wire Gauge or Range - AWG 16-28 AWG
Torque - Screw 0.25 Nm (2.2 Lb-In)
Number of Ways 4
Safety Approval UL; CSA
Plug Wire Entry 270°
Wire Strip Length 6.35mm
Max Supply Voltage (AC) 300V
Dimensions
Length 14mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
