ELFK07410
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
ELFK RoHS Compliant 2003 Retention Latches (Non-Wire Side) Terminal Block Plug, Female Sockets 26AWG 105C 15A 300V
PDF
/
Inventory: 4964
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Technical
Number of Positions Per Level 7
Wire Strip Length 7.87mm
Plug Wire Entry 45°
Positions Per Level 7
Torque - Screw 0.79 Nm (7.0 Lb-In)
Current - UL 15A
Wire Gauge or Range - AWG 12-26 AWG
Voltage - UL 300V
Contact Mating Finish Nickel
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 26 AWG
Current 15A
Number of Levels 1
Number of Circuits 7
Voltage 300V
Housing Color Black
Number of Contacts 7
Termination Style Screw - Rising Cage Clamp
Insulation Height 0.609 15.47mm
Pitch 0.300 7.62mm
Gender Female
Number of Rows 1
Color Black
Number of Positions 7
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Retention Latches (Non-Wire Side)
Series ELFK
Published 2003
Packaging Tray
Operating Temperature 105°C
Physical
Housing Material Polyphenylene Oxide (PPO)
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
