Package /
Category Connectors, Interconnects / Terminal Blocks - Barrier Blocks
Description M ROHS3Compliant Flange Closed Terminal Block Barrier Block UL94V-0 22AWG 150C 15A
PDF
/
Buying Options
Total Price: USD $92.48
Unit Price: USD $92.476737
≥1 USD $92.476737
≥200 USD $36.899055
≥500 USD $35.666241
≥1000 USD $35.057056
Inventory: 4168
Minimum: 1
-
+

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Technical

Number of Wire Entries 36
Top Termination Screws
Barrier Type 2 Wall (Dual)
Bottom Termination Closed
Terminal Block Type Barrier Block
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 22 AWG
Number of Circuits 18
Wire Gauge 14-22 AWG
Current Rating 15A
Pitch 0.500 12.70mm
Current Rating (Amps) 15A
Number of Rows 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Flange
Series M
Packaging Bulk
Operating Temperature 150°C

Physical

Terminal Material Steel
Terminal Screw Material Steel
Material - Insulation Phenol Formaldehyde (Phenolic)
Mounting Type Chassis, Panel
Mount Chassis, Panel

Supply Chain

Factory Lead Time 5 Weeks
