RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Accessories
Description
Buchanan RT2 RoHS Compliant CSA; CUL; UL; VDE Connector Screw 50000Cycle(s) 9ms 16A@250VAC 400mW
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.0472
≥1 USD $1.0472
≥10 USD $1.0208
≥100 USD $0.99528
≥500 USD $0.89584
≥1000 USD $0.871024
≥3000 USD $0.808808
Inventory: 65
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.089 inch
Body Height 16mm
Technical
Coil Release Voltage(DC) 2.4V
Coil Operate Voltage(DC) 16.8V
Relay Form 1 FORM A
Coil Current(DC)-Max 0.017A
Coil Voltage(DC)-Max 24V
Relay Function SPST
Dielectric Strength Between Coil and Contacts 5000 Vrms
PCB Hole Count 7
Relay Action MOMENTARY
Contact Voltage(AC)-Max 250V
Coil Power 400mW
Release Time 9 ms
Coil Voltage 24V
Operate Time 14 ms
Contact (AC) Max Rating R Load 16A@250VAC
Coil Resistance 1440Ohm
Contact Current(AC)-Max 16A
Electrical Life 50000 Cycle(s)
Sealing RT2
Operating Temperature (Min) -40°C
Physical Dimension 29mm x 12.7mm x 16mm
Body Breadth 12.7 mm
Operating Temperature (Max) 85°C
Body Length or Diameter 29mm
Reference Standard CSA; CUL; UL; VDE
Packing Method BOX; TUBE
Type Screw
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Buchanan
Physical
End Contact Material Silver Tin Oxide
Weight 14g
Mounting Feature THROUGH HOLE-STRAIGHT MOUNT
Surface Mount NO
Supply Chain
Factory Lead Time 23 Weeks
