1825955-4
RoHS
/
Package /
Category Switches / Tactile Switches
Description
PDF
/
Inventory: 9099
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Actuator Length 0.232 inch
Length - Termination 0.138 inch
Body Height 3.6mm
Technical
Circuit Configuration 1X1
Operating Force-Max 2.06 N
Number of Switches 1
Switch Action MOMENTARY-TACTILE
Contact Function OFF-(ON)
Actuator Color BLACK
PCB Hole Count 4
Contact (DC) Max Rating R Load .05A@24VDC
Switch Type KEYPAD SWITCH
Electrical Life 100000 Cycle(s)
Dielectric Withstanding Voltage 500VAC V
Termination Type SOLDER
Contact Voltage(DC)-Max 24V
Contact Current(DC)-Max 0.05A
Insulation Resistance 100000000Ohm
Contact Resistance 0.1mOhm
Switch Function SPST
Operating Temperature (Min) -35°C
Actuator Type PUSHBUTTON
Body Breadth 5.99 mm
Operating Temperature (Max) 85°C
Body Length or Diameter 5.99mm
HTS Code 8536.50.90.40
ECCN Code EAR99
Physical
End Contact Plating SILVER
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material COPPER ALLOY
Center Contact Plating SILVER
Housing Material POLYAMIDE
Mounting Feature THROUGH HOLE-STRAIGHT
Surface Mount NO
