CF-CA-1CB4-P101T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 32V
PDF
/
Inventory: 4340
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Actuator Material Resin
Technical
Operating Temperature -40°C~90°C
Packaging Tape & Reel (TR)
Published 2016
Series CF-CA
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Max Operating Temperature 90°C
Min Operating Temperature -40°C
Termination Style SMD (SMT) Tab
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Throw Configuration SPST
Illumination Non-Illuminated
Operating Force 305gf
Illumination Type Non-Illuminated
Actuator Orientation Side Actuated
Outline 7.60mm x 4.40mm
Contact Rating @ Voltage 0.05A @ 32VDC
Switch Travel 0.25mm
Dimensions
Actuator Length, Right Angle 5.70mm
Compliance
RoHS Status ROHS3 Compliant
