95C06F2GWRT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Inventory: 9786
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Body Height 3.5mm
Technical
Number of Switches 1
Actuator Height off PCB, Vertical 7.30mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.20mm x 6.20mm
Contact (DC) Max Rating R Load .05A@12VDC
Actuator Orientation Top Actuated
Operating Force 100gf
Switch Type KEYPAD SWITCH
Mechanical Life 1,000,000 Cycles
Max Voltage Rating (DC) 12V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 1000000 Cycle(s)
Contact Current(DC)-Max 0.05A
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Plunger for Cap
Body Breadth 6.2 mm
Body Length or Diameter 6.2mm
Termination Style Gull Wing
Packing Method TAPE AND REEL; TUBE
HTS Code 8536.50.90.40
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Tactile Feedback
JESD-609 Code e4
Series 95C
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -25°C~70°C
Physical
Actuator Material Polyamide (PA), Nylon
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
Contact Material Stainless Steel
Supply Chain
Factory Lead Time 16 Weeks
