TL6304NF300QJ

E-Switch
RoHS
/
Package /
Category Switches / Tactile Switches
Description SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Inventory: 7368
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount

Technical

Packaging Tape & Reel (TR)
Published 2005
Series TL6304
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Termination Style SMD (SMT) Tab
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Throw Configuration SPST
Illumination Non-Illuminated
Mechanical Life 100,000 Cycles
Operating Force 300gf
Actuator Orientation Top Actuated
Outline 6.20mm x 6.20mm
Contact Rating @ Voltage 0.05A @ 12VDC
Switch Travel 0.25mm
Actuator Height off PCB, Vertical 2.50mm

Compliance

RoHS Status RoHS Compliant
